自动摘要: 简单的HTML基础 ```html <!DOCTYPEhtml> <metacharset=”utf8”> HTML基础 ……..

简单的HTML基础

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
<!DOCTYPE html>
<html>
<head>
<meta charset="utf-8">
<title>HTML基础</title>
</head>
<body>
<!--标题通过<h1>-<h6>标签来定义-->
<h1>我的第一个标题</h1>
<h2>我的第二个标题</h2>
<!--段落通过<p>标签来定义-->
<p>我的第一个段落。</p>
<!--图像通过<img>标签来定义,图像的名称尺寸是以属性的形式提供的-->
<img src="/images/logo.jpg" width="255" height="255"/><br>
<!--链接通过<a>标签来定义,在href属性中指定链接的地址-->
<a href="www.baidu.com">百度</a>
</body>
</html>
标签 描述
定义 HTML 文档
定义文档的主体

-

定义 HTML 标题

定义水平线
定义注释

插入换行

定义一个段落

HTML 元素语法

  • HTML 元素以开始标签起始
  • HTML 元素以结束标签终止
  • 元素的内容是开始标签与结束标签之间的内容
  • 某些 HTML 元素具有空内容(empty content)
  • 空元素在开始标签中进行关闭(以开始标签的结束而结束)
  • 大多数 HTML 元素可拥有属性
    1
    2
    3
    4
    5
    6
    7
    8
    9
    <!DOCTYPE html>
    <html>

    <body>
    <p>这是第一个段落。</p>
    </body>

    </html>
    <!--上述代码中包含三个元素-->

HTML 属性

  • HTML 元素可以设置属性
  • 属性可以在元素中添加附加信息
  • 属性一般描述于开始标签
  • 属性总是以名称/值对的形式出现,**比如:name=”value”**。

下面列出了适用于大多数 HTML 元素的属性:

属性 描述
class 为html元素定义一个或多个类名(classname)(类名从样式文件引入)
id 定义元素的唯一id
style 规定元素的行内样式(inline style)
title 描述了元素的额外信息 (作为工具条使用)

HTML 文本格式化标签

标签 描述
定义粗体文本
定义着重文字
定义斜体字
定义小号字
定义加重语气
定义下标字
定义上标字
定义插入字
定义删除字

HTML “计算机输出” 标签

标签 描述
定义计算机代码
定义键盘码
定义计算机代码样本
定义变量
定义预格式文本

HTML 引文, 引用, 及标签定义

标签 描述
定义缩写
定义地址
定义文字方向
定义长的引用
定义短的引用语
定义引用、引证
定义一个定义项目。

HTML 链接

href属性:指定链接的地址target属性:使用 target 属性,你可以定义被链接的文档在何处显示。id属性:id 属性可用于创建一个 HTML 文档书签。

HTML head 元素

标签 描述
定义了文档的信息
